zimmer索玛gpp5000系列2爪平行抓爪
索玛gpp5000出色的导向概念钢/钢制导轨具有持久的精度，坚固性和耐用性，维护间隔可达3000万次。从这些属性中受益，并使用它们来提高机器的效率和过程可靠性。密封并具有防腐蚀功能-通用抓手适用于几乎所有环境条件，其导向装置密封等级达到ip67和标准防腐蚀保护，您可以通用使用该抓手。这样可以减少生产中类型的多样性以及相关的存储和过程成本。zimmer铝质直线导轨-替代精简的钢/铝质导轨替代品比具有t型槽滑动导轨的同类夹持器为您提供了明显更好的性能，并且与大多数齿形导轨原理相提并论。
zimmer索玛gpp5000系列各个型号参数
| gpp5003 | 每下巴行程 | 关闭时的抓力 | 打开时的抓力 |
|---|
| gpp5003n-00-a | 2.5 [毫米] | 140 [n] | 150 [n] |
| gpp5003nc-00-a | 2.5 [毫米] | 195 [n] |
|
| gpp5003no-00-a | 2.5 [毫米] |
| 205 [n] |
| gpp5003n-20-a | 2.5 [毫米] | 140 [n] | 150 [n] |
| gpp5003nc-20-a | 2.5 [毫米] | 195 [n] |
|
| gpp5003no-20-a | 2.5 [毫米] |
| 205 [n] |
| gpp5003n-21-a | 2.5 [毫米] | 140 [n] | 150 [n] |
| gpp5003nc-21-a | 2.5 [毫米] | 195 [n] |
|
| gpp5003no-21-a | 2.5 [毫米] |
| 205 [n] |
| gpp5003n-24-a | 2.5 [毫米] | 140 [n] | 150 [n] |
| gpp5003nc-24-a | 2.5 [毫米] | 195 [n] |
|
| gpp5003no-24-a | 2.5 [毫米] |
| 205 [n] |
| gpp5003n-al-a | 2.5 [毫米] | 140 [n] | 150 [n] |
| gpp5003nc-al-a | 2.5 [毫米] | 195 [n] |
|
| gpp5003no-al-a | 2.5 [毫米] |
| 205 [n] |
| gpp5004 | 每下巴行程 | 关闭时的抓力 | 打开时的抓力 |
|---|
| gpp5004n-00-a | 4 [毫米] | 200 [n] | 215 [n] |
| gpp5004nc-00-a | 4 [毫米] | 280 [n] |
|
| gpp5004no-00-a | 4 [毫米] |
| 295 [n] |
| gpp5004s-00-a | 2 [毫米] | 440 [n] | 470 [n] |
| gpp5004sc-00-a | 2 [毫米] | 600 [n] |
|
| gpp5004so-00-a | 2 [毫米] |
| 630 [n] |
| gpp5004n-20-a | 4 [毫米] | 200 [n] | 215 [n] |
| gpp5004nc-20-a | 4 [毫米] | 280 [n] |
|
| gpp5004no-20-a | 4 [毫米] |
| 295 [n] |
| gpp5004s-20-a | 2 [毫米] | 440 [n] | 470 [n] |
| gpp5004sc-20-a | 2 [毫米] | 600 [n] |
|
| gpp5004so-20-a | 2 [毫米] |
| 630 [n] |
| gpp5004n-21-a | 4 [毫米] | 200 [n] | 215 [n] |
| gpp5004nc-21-a | 4 [毫米] | 280 [n] |
|
| gpp5004no-21-a | 4 [毫米] |
| 295 [n] |
| gpp5004s-21-a | 2 [毫米] | 440 [n] | 470 [n] |
| gpp5004sc-21-a | 2 [毫米] | 600 [n] |
|
| gpp5004so-21-a | 2 [毫米] |
| 630 [n] |
| gpp5004n-24-a | 4 [毫米] | 200 [n] | 215 [n] |
| gpp5004nc-24-a | 4 [毫米] | 280 [n] |
|
| gpp5004no-24-a | 4 [毫米] |
| 295 [n] |
| gpp5004s-24-a | 2 [毫米] | 440 [n] | 470 [n] |
| gpp5004sc-24-a | 2 [毫米] | 600 [n] |
|
| gpp5004so-24-a | 2 [毫米] |
| 630 [n] |
| gpp5004n-al-a | 4 [毫米] | 200 [n] | 215 [n] |
| gpp5004nc-al-a | 4 [毫米] | 280 [n] |
|
| gpp5004no-al-a | 4 [毫米] |
| 295 [n] |
| gpp5006 | 每下巴行程 | 关闭时的抓力 | 打开时的抓力 |
|---|
| gpp5006n-00-a | 6 [毫米] | 330 [n] | 360 [n] |
| gpp5006nc-00-a | 6 [毫米] | 455 [n] |
|
| gpp5006no-00-a | 6 [毫米] |
| 485 [n] |
| gpp5006s-00-a | 3 [毫米] | 740 [n] | 800 [n] |
| gpp5006sc-00-a | 3 [毫米] | 1020 [n] |
|
| gpp5006so-00-a | 3 [毫米] |
| 1080 [n] |
| gpp5006n-20-a | 6 [毫米] | 330 [n] | 360 [n] |
| gpp5006nc-20-a | 6 [毫米] | 455 [n] |
|
| gpp5006no-20-a | 6 [毫米] |
| 485 [n] |
| gpp5006s-20-a | 3 [毫米] | 740 [n] | 800 [n] |
| gpp5006sc-20-a | 3 [毫米] | 1020 [n] |
|
| gpp5006so-20-a | 3 [毫米] |
| 1080 [n] |
| gpp5006n-21-a | 6 [毫米] | 330 [n] | 360 [n] |
| gpp5006nc-21-a | 6 [毫米] | 455 [n] |
|
| gpp5006no-21-a | 6 [毫米] |
| 485 [n] |
| gpp5006s-21-a | 3 [毫米] | 740 [n] | 800 [n] |
| gpp5006sc-21-a | 3 [毫米] | 1020 [n] |
|
| gpp5006so-21-a | 3 [毫米] |
| 1080 [n] |
| gpp5006n-24-a | 6 [毫米] | 330 [n] | 360 [n] |
| gpp5006nc-24-a | 6 [毫米] | 455 [n] |
|
| gpp5006no-24-a | 6 [毫米] |
| 485 [n] |
| gpp5006s-24-a | 3 [毫米] | 740 [n] | 800 [n] |
| gpp5006sc-24-a | 3 [毫米] | 1020 [n] |
|
| gpp5006so-24-a | 3 [毫米] |
| 1080 [n] |
| gpp5006n-al-a | 6 [毫米] | 330 [n] | 360 [n] |
| gpp5006nc-al-a | 6 [毫米] | 455 [n] |
|
| gpp5006no-al-a | 6 [毫米] |
| 485 [n] |
| gpp5008 | 每下巴行程 | 关闭时的抓力 | 打开时的抓力 |
|---|
| gpp5008n-00-a | 8 [毫米] | 520 [n] | 560 [n] |
| gpp5008nc-00-a | 8 [毫米] | 710 [n] |
|
| gpp5008no-00-a | 8 [毫米] |
| 750 [n] |
| gpp5008s-00-a | 4 [毫米] | 1150 [n] | 1240 [n] |
| gpp5008sc-00-a | 4 [毫米] | 1580 [n] |
|
| gpp5008so-00-a | 4 [毫米] |
| 1670 [n] |
| gpp5008n-20-a | 8 [毫米] | 520 [n] | 560 [n] |
| gpp5008nc-20-a | 8 [毫米] | 710 [n] |
|
| gpp5008no-20-a | 8 [毫米] |
| 750 [n] |
| gpp5008s-20-a | 4 [毫米] | 1150 [n] | 1240 [n] |
| gpp5008sc-20-a | 4 [毫米] | 1580 [n] |
|
| gpp5008so-20-a | 4 [毫米] |
| 1670 [n] |
| gpp5008n-21-a | 8 [毫米] | 520 [n] | 560 [n] |
| gpp5008nc-21-a | 8 [毫米] | 710 [n] |
|
| gpp5008no-21-a | 8 [毫米] |
| 750 [n] |
| gpp5008s-21-a | 4 [毫米] | 1150 [n] | 1240 [n] |
| gpp5008sc-21-a | 4 [毫米] | 1580 [n] |
|
| gpp5008so-21-a | 4 [毫米] |
| 1670 [n] |
| gpp5008n-24-a | 8 [毫米] | 520 [n] | 560 [n] |
| gpp5008nc-24-a | 8 [毫米] | 710 [n] |
|
| gpp5008no-24-a | 8 [毫米] |
| 750 [n] |
| gpp5008s-24-a | 4 [毫米] | 1150 [n] | 1240 [n] |
| gpp5008sc-24-a | 4 [毫米] | 1580 [n] |
|
| gpp5008so-24-a | 4 [毫米] |
| 1670 [n] |
| gpp5008n-al-a | 8 [毫米] | 520 [n] | 560 [n] |
| gpp5008nc-al-a | 8 [毫米] | 710 [n] |
|
| gpp5008no-al-a | 8 [毫米] |
| 750 [n] |
| gpp5010 | 每下巴行程 | 关闭时的抓力 | 打开时的抓力 |
|---|
| gpp5010n-00-a | 10 [毫米] | 885 [n] | 945 [n] |
| gpp5010nc-00-a | 10 [毫米] | 1260 [n] |
|
| gpp5010no-00-a | 10 [毫米] |
| 1320 [n] |
| gpp5010s-00-a | 5 [毫米] | 1940年[n] | 2080 [n] |
| gpp5010sc-00-a | 5 [毫米] | 2750 [n] |
|
| gpp5010so-00-a | 5 [毫米] |
| 2890 [n] |
| gpp5010n-20-a | 10 [毫米] | 885 [n] | 945 [n] |
| gpp5010nc-20-a | 10 [毫米] | 1260 [n] |
|
| gpp5010no-20-a | 10 [毫米] |
| 1320 [n] |
| gpp5010s-20-a | 5 [毫米] | 1940年[n] | 2080 [n] |
| gpp5010sc-20-a | 5 [毫米] | 2750 [n] |
|
| gpp5010so-20-a | 5 [毫米] |
| 2890 [n] |
| gpp5010n-21-a | 10 [毫米] | 885 [n] | 945 [n] |
| gpp5010nc-21-a | 10 [毫米] | 1260 [n] |
|
| gpp5010no-21-a | 10 [毫米] |
| 1320 [n] |
| gpp5010s-21-a | 5 [毫米] | 1940年[n] | 2080 [n] |
| gpp5010sc-21-a | 5 [毫米] | 2750 [n] |
|
| gpp5010so-21-a | 5 [毫米] |
| 2890 [n] |
| gpp5010n-24-a | 10 [毫米] | 885 [n] | 945 [n] |
| gpp5010nc-24-a | 10 [毫米] | 1260 [n] |
|
| gpp5010no-24-a | 10 [毫米] |
| 1320 [n] |
| gpp5010s-24-a | 5 [毫米] | 1940年[n] | 2080 [n] |
| gpp5010sc-24-a | 5 [毫米] | 2750 [n] |
|
| gpp5010so-24-a | 5 [毫米] |
| 2890 [n] |
| gpp5010n-al-a | 10 [毫米] | 885 [n] | 945 [n] |
| gpp5010nc-al-a | 10 [毫米] | 1260 [n] |
|
| gpp5010no-al-a | 10 [毫米] |
| 1320 [n] |
| gpp5013 | 每下巴行程 | 关闭时的抓力 | 打开时的抓力 |
|---|
| gpp5013n-00-a | 13 [毫米] | 1410 [n] | 1490 [n] |
| gpp5013nc-00-a | 13 [毫米] | 1920 [n] |
|
| gpp5013no-00-a | 13 [毫米] |
| 1860 [n] |
| gpp5013s-00-a | 6 [毫米] | 3100 [n] | 3280 [n] |
| gpp5013sc-00-a | 6 [毫米] | 4220 [n] |
|
| gpp5013so-00-a | 6 [毫米] |
| 4400 [n] |
| gpp5013n-20-a | 13 [毫米] | 1410 [n] | 1490 [n] |
| gpp5013nc-20-a | 13 [毫米] | 1920 [n] |
|
| gpp5013no-20-a | 13 [毫米] |
| 1860 [n] |
| gpp5013s-20-a | 6 [毫米] | 3100 [n] | 3280 [n] |
| gpp5013sc-20-a | 6 [毫米] | 4220 [n] |
|
| gpp5013so-20-a | 6 [毫米] |
| 4400 [n] |
| gpp5013n-21-a | 13 [毫米] | 1410 [n] | 1490 [n] |
| gpp5013nc-21-a | 13 [毫米] | 1920 [n] |
|
| gpp5013no-21-a | 13 [毫米] |
| 1860 [n] |
| gpp5013s-21-a | 6 [毫米] | 3100 [n] | 3280 [n] |
| gpp5013sc-21-a | 6 [毫米] | 4220 [n] |
|
| gpp5013so-21-a | 6 [毫米] |
| 4400 [n] |
| gpp5013n-24-a | 13 [毫米] | 1410 [n] | 1490 [n] |
| gpp5013nc-24-a | 13 [毫米] | 1920 [n] |
|
| gpp5013no-24-a | 13 [毫米] |
| 1860 [n] |
| gpp5013s-24-a | 6 [毫米] | 3100 [n] | 3280 [n] |
| gpp5013sc-24-a | 6 [毫米] | 4220 [n] |
|
| gpp5013so-24-a | 6 [毫米] |
| 4400 [n] |
| gpp5013n-al-a | 13 [毫米] | 1410 [n] | 1490 [n] |
| gpp5013nc-al-a | 13 [毫米] | 1920 [n] |
|
| gpp5013no-al-a | 13 [毫米] |
| 1860 [n] |
| gpp5016 | 每下巴行程 | 关闭时的抓力 | 打开时的抓力 |
|---|
| gpp5016n-00-a | 16 [毫米] | 2090 [n] | 2220 [n] |
| gpp5016nc-00-a | 16 [毫米] | 2860 [n] |
|
| gpp5016no-00-a | 16 [毫米] |
| 2990 [n] |
| gpp5016s-00-a | 8 [毫米] | 4610 [n] | 4900 [n] |
| gpp5016sc-00-a | 8 [毫米] | 6310 [n] |
|
| gpp5016so-00-a | 8 [毫米] |
| 6600 [n] |
| gpp5016n-20-a | 16 [毫米] | 2090 [n] | 2200 [n] |
| gpp5016nc-20-a | 16 [毫米] | 2860 [n] |
|
| gpp5016no-20-a | 16 [毫米] |
| 2990 [n] |
| gpp5016s-20-a | 8 [毫米] | 4610 [n] | 4900 [n] |
| gpp5016sc-20-a | 8 [毫米] | 6310 [n] |
|
| gpp5016so-20-a | 8 [毫米] |
| 6600 [n] |
| gpp5016n-21-a | 16 [毫米] | 2090 [n] | 2220 [n] |
| gpp5016nc-21-a | 16 [毫米] | 2860 [n] |
|
| gpp5016no-21-a | 16 [毫米] |
| 2990 [n] |
| gpp5016s-21-a | 8 [毫米] | 4610 [n] | 4900 [n] |
| gpp5016sc-21-a | 8 [毫米] | 6310 [n] |
|
| gpp5016so-21-a | 8 [毫米] |
| 6600 [n] |
| gpp5016n-24-a | 16 [毫米] | 2090 [n] | 2220 [n] |
| gpp5016nc-24-a | 16 [毫米] | 2860 [n] |
|
| gpp5016no-24-a | 16 [毫米] |
| 2990 [n] |
| gpp5016s-24-a | 8 [毫米] | 4610 [n] | 4900 [n] |
| gpp5016sc-24-a | 8 [毫米] | 6310 [n] |
|
| gpp5016so-24-a | 8 [毫米] |
| 6600 [n] |
| gpp5016n-al-a | 16 [毫米] | 2090 [n] | 2220 [n] |
| gpp5016nc-al-a | 16 [毫米] | 2860 [n] |
|
| gpp5016no-al-a | 16 [毫米] |
| 2990 [n] |
| gpp5025 | 每下巴行程 | 关闭时的抓力 | 打开时的抓力 |
|---|
| gpp5025n-00-a | 25 [毫米] | 3280 [n] | 3490 [n] |
| gpp5025nc-00-a | 25 [毫米] | 4510 [n] |
|
| gpp5025no-00-a | 25 [毫米] |
| 4710 [n] |
| gpp5025s-00-a | 14 [毫米] | 6360 [n] | 6760 [n] |
| gpp5025sc-00-a | 14 [毫米] | 8730 [n] |
|
| gpp5025so-00-a | 14 [毫米] |
| 9130 [n] |
| gpp5025n-20-a | 25 [毫米] | 3280 [n] | 3490 [n] |
| gpp5025nc-20-a | 25 [毫米] | 4510 [n] |
|
| gpp5025no-20-a | 25 [毫米] |
| 4710 [n] |
| gpp5025s-20-a | 14 [毫米] | 6360 [n] | 6760 [n] |
| gpp5025sc-20-a | 14 [毫米] | 8730 [n] |
|
| gpp5025so-20-a | 14 [毫米] |
| 9130 [n] |
| gpp5025n-21-a | 25 [毫米] | 3280 [n] | 3490 [n] |
| gpp5025nc-21-a | 25 [毫米] | 4510 [n] |
|
| gpp5025no-21-a | 25 [毫米] |
| 4710 [n] |
| gpp5025s-21-a | 14 [毫米] | 6360 [n] | 6760 [n] |
| gpp5025sc-21-a | 14 [毫米] | 8730 [n] |
|
| gpp5025so-21-a | 14 [毫米] |
| 9130 [n] |
| gpp5025n-24-a | 25 [毫米] | 3280 [n] | 3490 [n] |
| gpp5025nc-24-a | 25 [毫米] | 4510 [n] |
|
| gpp5025no-24-a | 25 [毫米] |
| 4710 [n] |
| gpp5025s-24-a | 14 [毫米] | 6360 [n] | 6760 [n] |
| gpp5025sc-24-a | 14 [毫米] | 8730 [n] |
|
| gpp5025so-24-a | 14 [毫米] |
| 9130 [n] |
| gpp5030 | 每下巴行程 | 关闭时的抓力 | 打开时的抓力 |
|---|
| gpp5030n-00-a | 30 [毫米] | 5000 [n] | 5210 [n] |
| gpp5030nc-00-a | 30 [毫米] | 6850 [n] |
|
| gpp5030no-00-a | 30 [毫米] |
| 7060 [n] |
| gpp5030s-00-a | 17 [毫米] | 9600 [n] | 9990 [n] |
| gpp5030sc-00-a | 17 [毫米] | 13160 [n] |
|
| gpp5030so-00-a | 17 [毫米] |
| 13550 [n] |
| gpp5030n-20-a | 30 [毫米] | 5000 [n] | 5210 [n] |
| gpp5030nc-20-a | 30 [毫米] | 6850 [n] |
|
| gpp5030no-20-a | 30 [毫米] |
| 7060 [n] |
| gpp5030s-20-a | 17 [毫米] | 9600 [n] | 9990 [n] |
| gpp5030sc-20-a | 17 [毫米] | 13160 [n] |
|
| gpp5030so-20-a | 17 [毫米] |
| 13550 [n] |
| gpp5030n-21-a | 30 [毫米] | 5000 [n] | 5210 [n] |
| gpp5030nc-21-a | 30 [毫米] | 6850 [n] |
|
| gpp5030no-21-a | 30 [毫米] |
| 7060 [n] |
| gpp5030s-21-a | 17 [毫米] | 9600 [n] | 9990 [n] |
| gpp5030sc-21-a | 17 [毫米] | 13160 [n] |
|
| gpp5030so-21-a | 17 [毫米] |
| 13550 [n] |
| gpp5030n-24-a | 30 [毫米] | 5000 [n] | 5210 [n] |
| gpp5030nc-24-a | 30 [毫米] | 6850 [n] |
|
| gpp5030no-24-a | 30 [毫米] |
| 7060 [n] |
| gpp5030s-24-a | 17 [毫米] | 9600 [n] | 9990 [n] |
| gpp5030sc-24-a | 17 [毫米] | 13160 [n] |
|
| gpp5030so-24-a | 17 [毫米] |
| 13550 [n] |
| gpp5035 | 每下巴行程 | 关闭时的抓力 | 打开时的抓力 |
|---|
| gpp5035n-00-a | 35 [毫米] | 6100 [n] | 6300 [n] |
| gpp5035nc-00-a | 35 [毫米] | 8000 [n] |
|
| gpp5035no-00-a | 35 [毫米] |
| 8200 [n] |
| gpp5035s-00-a | 20 [毫米] | 11700 [n] | 12100 [n] |
| gpp5035sc-00-a | 20 [毫米] | 15500 [n] |
|
| gpp5035so-00-a | 20 [毫米] |
| 15900 [n] |
| gpp5035n-20-a | 35 [毫米] | 6100 [n] | 6300 [n] |
| gpp5035nc-20-a | 35 [毫米] | 8000 [n] |
|
| gpp5035no-20-a | 35 [毫米] |
| 8200 [n] |
| gpp5035s-20-a | 20 [毫米] | 11700 [n] | 12100 [n] |
| gpp5035sc-20-a | 20 [毫米] | 15500 [n] |
|
| gpp5035so-20-a | 20 [毫米] |
| 15900 [n] |
| gpp5035n-21-a | 35 [毫米] | 6100 [n] | 6300 [n] |
| gpp5035nc-21-a | 35 [毫米] | 8000 [n] |
|
| gpp5035no-21-a | 35 [毫米] |
| 8200 [n] |
| gpp5035s-21-a | 20 [毫米] | 11700 [n] | 12100 [n] |
| gpp5035sc-21-a | 20 [毫米] | 15500 [n] |
|
| gpp5035so-21-a | 20 [毫米] |
| 15900 [n] |
| gpp5035n-24-a | 35 [毫米] | 6100 [n] | 6300 [n] |
| gpp5035nc-24-a | 35 [毫米] | 8000 [n] |
|
| gpp5035no-24-a | 35 [毫米] |
| 8200 [n] |
| gpp5035s-24-a | 20 [毫米] | 11700 [n] | 12100 [n] |
| gpp5035sc-24-a | 20 [毫米] | 15500 [n] |
|
| gpp5035so-24-a | 20 [毫米] |
| 15900 [n] |
| gpp5045 | 每下巴行程 | 关闭时的抓力 | 打开时的抓力 |
|---|
| gpp5045n-00-a | 45 [毫米] | 10200 [n] | 10700 [n] |
| gpp5045nc-00-a | 45 [毫米] | 13700 [n] |
|
| gpp5045no-00-a | 45 [毫米] |
| 14200 [n] |
| gpp5045s-00-a | 26 [毫米] | 19400 [n] | 20300 [n] |
| gpp5045sc-00-a | 26 [毫米] | 26050 [n] |
|
| gpp5045so-00-a | 26 [毫米] |
| 26950 [n] |
| gpp5045n-20-a | 45 [毫米] | 10200 [n] | 10700 [n] |
| gpp5045nc-20-a | 45 [毫米] | 13700 [n] |
|
| gpp5045no-20-a | 45 [毫米] |
| 14200 [n] |
| gpp5045s-20-a | 26 [毫米] | 19400 [n] | 20300 [n] |
| gpp5045sc-20-a | 26 [毫米] | 26050 [n] |
|
| gpp5045so-20-a | 26 [毫米] |
| 26950 [n] |
| gpp5045n-21-a | 45 [毫米] | 10200 [n] | 10700 [n] |
| gpp5045nc-21-a | 45 [毫米] | 13700 [n] |
|
| gpp5045no-21-a | 45 [毫米] |
| 14200 [n] |
| gpp5045s-21-a | 26 [毫米] | 19400 [n] | 20300 [n] |
| gpp5045sc-21-a | 26 [毫米] | 26050 [n] |
|
| gpp5045so-21-a | 26 [毫米] |
| 26950 [n] |
| gpp5045n-24-a | 45 [毫米] | 10200 [n] | 10700 [n] |
| gpp5045nc-24-a | 45 [毫米] | 13700 [n] |
|
| gpp5045no-24-a | 45 [毫米] |
| 14200 [n] |
| gpp5045s-24-a | 26 [毫米] | 19400 [n] | 20300 [n] |
| gpp5045sc-24-a | 26 [毫米] | 26050 [n] |
|
| gpp5045so-24-a | 26 [毫米] |
| 26950 [n] |
13701731174
