所属品牌:阿特拉斯·科普柯atlas copco
产品型号:ltc/lto系列
atlas 阿特拉斯ltc/lto 角度扳手属于气动扳手,该气动工具是动力、速度和精度的结合。在狭小难以到达的空间内,atlasltc/lto 角度扳手是理想的利记sbobet官网的解决方案,“c”代表crowfoot,对于难以到达的接头。“o”代表开口扳子头,适合于管螺母应用的利记sbobet官网的解决方案。同时阿特拉斯工具采用先进的人体工程学设计,对于用户及其的友好,有助于提高装配效率。
- 商品描述
- 商品询价热度
atlas 阿特拉斯ltc/lto气动角度扳手
atlas ltc/lto角度扳手优势特点
弯头高度低
高速旋入模式
扭矩重复性
由于的马达设计,降低了空气消耗量
atlas ltc/lto角度扳手各型号技术参数
title | id | 扭矩范围值> | 扭矩范值< | 空载速度 | 重量 | 长度 | a/f | a | b | c | d | e | g | h | r | 声压 | 声音标准 | 震动标准 | 震动值 | 扣爪类型 | 经过 eac 认证 | 工作压力< | 型号类型 | 可反转 | 断气式 | 声功率 | 声音不确定度 | 空转速度下的空气消耗量 | 进气口螺纹 | 螺栓尺寸 | ec 标准 | eu 指令 | f | 推荐的软管尺寸 | 振动不确定度 | j | 管螺母类型 | 6.3 bar 软接头下的扭矩< | 6.3 bar 软接头下的扭矩> |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
ltc29-2r19-10-lo3 | 8431061502 | 7.3 ft lb | 14 ft lb | 640 r/min | 4.4 lb | 384 mm | 10 mm | 60.3 mm | 15 mm | 14.55 mm | 32.8 mm | 42.8 mm | 36.5 mm | 22 mm | 10 mm | 80 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | angle | yes | yes | 90 db(a) | 3 db(a) | 10 l/s | 1/4 inch | m6 mm | iso 11148-6 | 2006/42/ec | 61.1 mm | 8 mm | 3 m/s² | ||||
lto38 r28-12-li3 | 8431061708 | 7 ft lb | 20 ft lb | 320 r/min | 6.4 lb | 514 mm | 12 mm | 43 mm | 11 mm | 17.5 mm | 43.7 mm | 29.3 mm | 40 mm | 50 mm | 15 mm | 82 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | yes | 100 psi | angle | yes | yes | 93 db(a) | 3 db(a) | iso 11148-6 | 2006/42/ec | 10.4 mm | in-line | |||||||||
lto28 sr005 | 8431053010 | 6 ft lb | 14 ft lb | 470 r/min | 2.4 lb | 280 mm | 76 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | yes | 100 psig | straight | yes | yes | 87 db(a) | 3 db(a) | iso 11148-6 | 2006/42/ec | ||||||||||||||||||||
ltc48 r120-19-ao3 | 8431061115 | 36 ft lb | 89 ft lb | 180 r/min | 9.6 lb | 656 mm | 19 mm | 87 mm | 25 mm | 42.3 mm | 67.6 mm | 87.4 mm | 54 mm | 39.5 mm | 19.75 mm | 84 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | angle | yes | yes | 95 db(a) | 3 db(a) | 28 l/s | 1/2 inch | m12 mm | iso 11148-6 | 2006/42/ec | 112.7 mm | 12.5 mm | 3 m/s² | ||||
ltc38 r40-17-ao3 | 8431061108 | 17 ft lb | 29 ft lb | 360 r/min | 6.7 lb | 519 mm | 17 mm | 66 mm | 19 mm | 45.1 mm | 67.6 mm | 87.2 mm | 45 mm | 39.2 mm | 19.5 mm | 82 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | angle | yes | yes | 93 db(a) | 3 db(a) | 16 l/s | 1/4 inch | m8 mm | iso 11148-6 | 2006/42/ec | 109.7 mm | 10 mm | 3 m/s² | ||||
ltc39-2r28-13-lo5 | 8431062053 | 13 ft lb | 24.3 ft lb | 550 r/min | 10.4 lb | 488 mm | 13 mm | 81 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | crowfoot | yes | yes | 92 db(a) | 3 db(a) | 16 l/s | 1/4 inch | m8 mm | iso 11148-6 | 2006/42/ec | 10 mm | 3 m/s² | |||||||||||||
ltc009 r13-10e5m-li3 | 8431062088 | 3.7 ft lb | 9.6 ft lb | 125 r/min | 4 lb | 316 mm | 75 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | in-line | yes | 100 psig | crowfoot | yes | yes | 3 db(a) | iso11148-6 | 2006/42/ec | ||||||||||||||||||||
ltc38 r44-12-lo5 | 8431061493 | 18 ft lb | 32 ft lb | 210 r/min | 8.4 lb | 593 mm | 12 mm | 82 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | crowfoot | yes | yes | 93 db(a) | 3 db(a) | 16 l/s | 1/4 inch | m8 mm | iso 11148-6 | 2006/42/ec | 10 mm | 3 m/s² | |||||||||||||
ltc29-2r21-13-lo5 | 8431061504 | 8 ft lb | 15 ft lb | 500 r/min | 4.4 lb | 457 mm | 13 mm | 58.5 mm | 10 mm | 71.6 mm | 93.6 mm | 108.1 mm | 44 mm | 31 mm | 14.5 mm | 80 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | angle | yes | yes | 90 db(a) | 3 db(a) | 10 l/s | 1/4 inch | m6 mm | iso 11148-6 | 2006/42/ec | 130.1 mm | 8 mm | 3 m/s² | ||||
ltc39-2r30-13-lo9 | 8431062051 | 13 ft lb | 22 ft lb | 440 r/min | 8.4 lb | 625 mm | 13 mm | 81 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | crowfoot | yes | yes | 92 db(a) | 3 db(a) | 16 l/s | 1/4 inch | m8 mm | iso 11148-6 | 2006/42/ec | 10 mm | 3 m/s² | |||||||||||||
ltc009 r12-10-li3 | 8431061364 | 3.6 ft lb | 9 ft lb | 120 r/min | 2.9 lb | 312 mm | 10 mm | 34 mm | 15 mm | 12.5 mm | 36.7 mm | 59 mm | 35 mm | 22 mm | 10 mm | 75 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | in-line | yes | 100 psi | angle | yes | yes | 3 db(a) | iso 11148-6 | 2006/42/ec | |||||||||||
lto28 r12-10-li3 | 8431061244 | 4 ft lb | 8 ft lb | 420 r/min | 4.4 lb | 396 mm | 10 mm | 32 mm | 10 mm | 13 mm | 27.3 mm | 25.4 mm | 33.5 mm | 31 mm | 9.8 mm | 76 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | yes | 100 psi | angle | yes | yes | 3 db(a) | iso 11148-6 | 2006/42/ec | 7 mm | in-line | ||||||||||
ltc009 r13-10-li3 | 8431061601 | 4 ft lb | 9 ft lb | 127 r/min | 4 lb | 312 mm | 10 mm | 34 mm | 15 mm | 12.5 mm | 46.7 mm | 59.2 mm | 35 mm | 22 mm | 10 mm | 76 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | in-line | yes | 100 psi | angle | yes | yes | 3 db(a) | iso 11148-6 | 2006/42/ec | |||||||||||
ltc39-2r60-16-lo3 | 8431061514 | 25 ft lb | 44 ft lb | 305 r/min | 6.7 lb | 541 mm | 16 mm | 91 mm | 24 mm | 27 mm | 51 mm | 66 mm | 48 mm | 30 mm | 15 mm | 81 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | angle | yes | yes | 92 db(a) | 3 db(a) | 16 l/s | 1/4 inch | m10 mm | iso 11148-6 | 2006/42/ec | 91.5 mm | 10 mm | 3 m/s² | ||||
ltc39-2r44-13e10-lo3 | 8431061988 | 17 ft lb | 32 ft lb | 430 r/min | 6 lb | 470 mm | 13 mm | 81 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | angle | yes | yes | 92 db(a) | 3 db(a) | 16 l/s | 1/4 inch | m8 mm | iso 11148-6 | 2006/42/ec | 10 mm | 3 m/s² | |||||||||||||
ltc39-2r28-13e10-lo4 | 8431062082 | 10 ft lb | 20 ft lb | 700 r/min | 4.85 lb | 475 mm | 13 mm | 81 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | angle | yes | yes | 92 db(a) | 3 db(a) | 16 l/s | 1/4 inch | m8 mm | iso 11148-6 | 2006/42/ec | 10 mm | 3 m/s² | |||||||||||||
ltc38 r33-13-ao3 | 8431061101 | 11.8 ft lb | 24 ft lb | 430 r/min | 5.8 lb | 487 mm | 13 mm | 60 mm | 19 mm | 32.8 mm | 52.8 mm | 68.8 mm | 40 mm | 34 mm | 16 mm | 82 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | angle | yes | yes | 93 db(a) | 3 db(a) | 16 l/s | 1/4 inch | m8 mm | iso 11148-6 | 2006/42/ec | 88.8 mm | 10 mm | 3 m/s² | ||||
ltc38 r34-21-li3 | 8431061610 | 12 ft lb | 25 ft lb | 390 r/min | 8.2 lb | 578 mm | 21 mm | 46 mm | 20 mm | 16 mm | 74.5 mm | 44 mm | 64 mm | 40 mm | 20 mm | 78 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | in-line | yes | 100 psi | angle | yes | yes | 3 db(a) | iso 11148-6 | 2006/42/ec | |||||||||||
lto38 r18-11-lo5 | 8431062083 | 9.6 ft lb | 13.3 ft lb | 270 r/min | 8 lb | 497 mm | 11 mm | 82 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | yes | 100 psig | angle | yes | yes | 93 db(a) | 3 db(a) | iso 11148-6 | 2006/42/ec | offset | ||||||||||||||||||
ltc39-2r28-5/16-lo5 | 8431061934 | 13 ft lb | 21 ft lb | 530 r/min | 10.4 lb | 488 mm | 7.94 mm | 81 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | crowfoot | yes | yes | 92 db(a) | 3 db(a) | 16 l/s | 1/4 inch | m8 mm | iso 11148-6 | 2006/42/ec | 10 mm | 3 m/s² | |||||||||||||
lto38 r26-17-li3 | 8431061254 | 14 ft lb | 26 ft lb | 200 r/min | 7.1 lb | 547 mm | 17 mm | 46 mm | 12 mm | 20 mm | 60.3 mm | 38.8 mm | 45 mm | 59 mm | 20.1 mm | 82 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | yes | 100 psi | angle | yes | yes | 93 db(a) | 3 db(a) | iso 11148-6 | 2006/42/ec | 16 mm | in-line | |||||||||
lto28 r6-13-li3 | 8431062002 | 1.5 ft lb | 4.4 ft lb | 827 r/min | 4.4 lb | 0 mm | 76 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | yes | 0 psig | straight | yes | yes | 0 db(a) | 3 db(a) | iso 11148-6 | 2006/42/ec | in-line | |||||||||||||||||||
ltc39-2r18-10-lo5 | 8431062073 | 8 ft lb | 15 ft lb | 870 r/min | 4.1 lb | 452 mm | 10 mm | 81 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | crowfoot | yes | yes | 92 db(a) | 3 db(a) | 16 l/s | 1/4 inch | m6 mm | iso 11148-6 | 2006/42/ec | 10 mm | 3 m/s² | |||||||||||||
ltc39-2 r38-13-lo3 | 8431061341 | 12 ft lb | 28 ft lb | 540 r/min | 5.6 lb | 450 mm | 13 mm | 81 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | crowfoot | yes | yes | 92 db(a) | 3 db(a) | 16 l/s | 1/4 inch | m8 mm | iso 11148-6 | 2006/42/ec | 10 mm | 3 m/s² | |||||||||||||
ltc48 r65-sf15e5-li3 | 8431062091 | 22 ft lb | 48 ft lb | 220 r/min | 10 lb | 700 mm | 82 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | in-line 8-43-24 | yes | 100 psig | crowfoot | yes | yes | 93 db(a) | 3 db(a) | 28 l/s | 1/2 inch | m10 mm | iso 11148-6 | 2006/42/ec | 12.5 mm | 3 m/s² | ||||||||||||||
lto38 r40 | 8431053632 | 10 ft lb | 29 ft lb | 200 r/min | 3.3 lb | 354 mm | 82 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | yes | 100 psig | straight | yes | yes | 93 db(a) | 3 db(a) | iso 11148-6 | 2006/42/ec | in-line | |||||||||||||||||||
lto 009r07-13-lo5 | 8431062081 | 2.2 ft lb | 5.2 ft lb | 130 r/min | 2.2 lb | 323 mm | 75 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | yes | 100 psi | angle | yes | yes | 96 db(a) | 3 db(a) | iso 11148-6 | 2006/42/ec | offset | |||||||||||||||||||
ltc29-2r21-t8e14-lo5 | 8431061552 | 8 ft lb | 15 ft lb | 500 r/min | 4.4 lb | 457 mm | 14 mm | 58.5 mm | 10 mm | 71.6 mm | 93.6 mm | 108.1 mm | 44 mm | 31 mm | 14.5 mm | 80 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | angle | yes | yes | 90 db(a) | 3 db(a) | 10 l/s | 1/4 inch | m6 mm | iso 11148-6 | 2006/42/ec | 130.1 mm | 8 mm | 3 m/s² | ||||
ltc39-2 r28-12e5-lo5 | 8431062111 | 10 ft lb | 21 ft lb | 550 r/min | 5.5 lb | 490 mm | 12 mm | 81 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | crowfoot | yes | yes | 92 db(a) | 3 db(a) | 16 l/s | 1/4 inch | m8 mm | iso 11148-6 | 2006/42/ec | 10 mm | 3 m/s² | |||||||||||||
ltc48 r96-18-lo3 | 8431061521 | 41 ft lb | 71 ft lb | 210 r/min | 10.4 lb | 651 mm | 18 mm | 99 mm | 32 mm | 32 mm | 63.2 mm | 82.2 mm | 62.5 mm | 38 mm | 19 mm | 84 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | angle | yes | yes | 95 db(a) | 3 db(a) | 28 l/s | 1/2 inch | m12 mm | iso 11148-6 | 2006/42/ec | 113.5 mm | 12.5 mm | 3 m/s² | ||||
ltc39-2r65-13e15-lo3 | 8431062012 | 25 ft lb | 48 ft lb | 305 r/min | 6.6 lb | 560 mm | 13 mm | 81 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | crowfoot | yes | yes | 92 db(a) | 3 db(a) | 16 l/s | 1/4 inch | m10 mm | iso 11148-6 | 2006/42/ec | 10 mm | 3 m/s² | |||||||||||||
lto38 r43-10 | 8431053003 | 12 ft lb | 32 ft lb | 280 r/min | 4.4 lb | 454 mm | 82 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | yes | 100 psig | angle | yes | yes | 93 db(a) | 3 db(a) | iso 11148-6 | 2006/42/ec | ||||||||||||||||||||
lto38 r40-16-li3 | 8431062071 | 15 ft lb | 30 ft lb | 625 r/min | 5.5 lb | 0 mm | 82 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | yes | 0 psig | crowfoot | yes | yes | 93 db(a) | 3 db(a) | iso 11148-6 | 2006/42/ec | in-line | |||||||||||||||||||
ltc48 r80-21-li3 | 8431061612 | 37 ft lb | 59 ft lb | 250 r/min | 8.9 lb | 578 mm | 21 mm | 46 mm | 20 mm | 16 mm | 74.5 mm | 84 mm | 64 mm | 40 mm | 20 mm | 78 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | in-line | yes | 100 psi | angle | yes | yes | 3 db(a) | iso 11148-6 | 2006/42/ec | |||||||||||
ltc38 r34-13-li3 | 8431062107 | 12 ft lb | 25 ft lb | 390 r/min | 8.2 lb | 578 mm | 13 mm | 46 mm | 20 mm | 16 mm | 74.5 mm | 44 mm | 64 mm | 40 mm | 20 mm | 78 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | in-line | yes | 100 psig | crowfoot | yes | yes | 3 db(a) | iso 11148-6 | 2006/42/ec | |||||||||||
ltc009 r08-10-li3 | 8431061372 | 2.9 ft lb | 6 ft lb | 210 r/min | 2.9 lb | 312 mm | 10 mm | 34 mm | 10 mm | 13.5 mm | 37 mm | 41 mm | 35 mm | 22 mm | 10 mm | 75 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | in-line | yes | 100 psi | angle | yes | yes | 3 db(a) | iso 11148-6 | 2006/42/ec | |||||||||||
ltc009 r07-10-lo3 | 8431061494 | 2.2 ft lb | 5 ft lb | 250 r/min | 3.6 lb | 304 mm | 10 mm | 59.5 mm | 10 mm | 14.55 mm | 32.8 mm | 42.8 mm | 36.5 mm | 22 mm | 10 mm | 75 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | angle | yes | yes | 86 db(a) | 3 db(a) | 6 l/s | 1/4 inch | m5 mm | iso 11148-6 | 2006/42/ec | 61.1 mm | 6 mm | 3 m/s² | ||||
ltc39-2r49-13-lo5 | 8431062048 | 18 ft lb | 36 ft lb | 360 r/min | 6 lb | 508 mm | 13 mm | 81 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | angle | yes | yes | 92 db(a) | 3 db(a) | 16 l/s | 1/4 inch | m10 mm | iso 11148-6 | 2006/42/ec | 10 mm | 3 m/s² | |||||||||||||
ltc48 r56-17-ao3 | 8431061106 | 18 ft lb | 41 ft lb | 400 r/min | 8.7 lb | 619 mm | 17 mm | 66 mm | 19 mm | 45.1 mm | 67.6 mm | 87.2 mm | 45 mm | 39.2 mm | 19.5 mm | 84 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | angle | yes | yes | 95 db(a) | 3 db(a) | 28 l/s | 1/2 inch | m10 mm | iso 11148-6 | 2006/42/ec | 109.7 mm | 12.5 mm | 3 m/s² | ||||
ltc28 r22-12-li3 | 8431061608 | 8 ft lb | 16 ft lb | 345 r/min | 4 lb | 433 mm | 12 mm | 34 mm | 15 mm | 12.5 mm | 45.5 mm | 71 mm | 35 mm | 30 mm | 13 mm | 76 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | in-line | yes | 100 psi | crowfoot | yes | yes | 3 db(a) | iso 11148-6 | 2006/42/ec | |||||||||||
lto38 r43-14-li3 | 8431061710 | 10 ft lb | 31 ft lb | 220 r/min | 7.1 lb | 522 mm | 14 mm | 46 mm | 18 mm | 17 mm | 41 mm | 38.5 mm | 45 mm | 50 mm | 15 mm | 82 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | yes | 100 psi | angle | yes | yes | 93 db(a) | 3 db(a) | iso 11148-6 | 2006/42/ec | 12 mm | in-line | |||||||||
lto38 r35-12-li3 | 8431061709 | 10 ft lb | 25 ft lb | 220 r/min | 6.4 lb | 519 mm | 12 mm | 43 mm | 11 mm | 17.5 mm | 43.7 mm | 29.3 mm | 40 mm | 50 mm | 15 mm | 82 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | yes | 100 psi | angle | yes | yes | 93 db(a) | 3 db(a) | iso 11148-6 | 2006/42/ec | 10.4 mm | in-line | |||||||||
lto38 r26-13-li3 | 8431061250 | 11 ft lb | 22 ft lb | 220 r/min | 6.7 lb | 536 mm | 13 mm | 46 mm | 11 mm | 20.8 mm | 52 mm | 47.3 mm | 45 mm | 55 mm | 17.2 mm | 82 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | yes | 100 psi | angle | yes | yes | 93 db(a) | 3 db(a) | iso 11148-6 | 2006/42/ec | 12.5 mm | in-line | |||||||||
ltc39-2r50-13sfd-li5 | 8431062105 | 16 ft lb | 44 ft lb | 240 r/min | 8.8 lb | 570 mm | 81 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | in-line | yes | 100 psig | angle | yes | yes | 92 db(a) | 3 db(a) | 16 l/s | 1/4 inch | iso 11148-6 | 2006/42/ec | 10 mm | 60 nm | 22 nm | ||||||||||||||
ltc38 r28-12-li3 | 8431061609 | 10 ft lb | 20 ft lb | 470 r/min | 4 lb | 493 mm | 12 mm | 34 mm | 15 mm | 12.5 mm | 45.5 mm | 71 mm | 35 mm | 30 mm | 13 mm | 78 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | in-line | yes | 100 psi | angle | yes | yes | 3 db(a) | iso 11148-6 | 2006/42/ec | |||||||||||
ltc29-2r11-sq14-lo5 | 8431062099 | 4.4 ft lb | 8.1 ft lb | 850 r/min | 4.4 lb | 415 mm | 14 mm | 80 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | crowfoot | yes | yes | 90 db(a) | 3 db(a) | 10 l/s | 1/4 inch | m5 mm | iso 11148-6 | 2006/42/ec | 8 mm | 3 m/s² | |||||||||||||
lto28 r15-10-li3 | 8431061246 | 4 ft lb | 11 ft lb | 400 r/min | 4.4 lb | 397 mm | 10 mm | 32 mm | 12 mm | 11 mm | 27.9 mm | 26.1 mm | 33.5 mm | 32 mm | 10.3 mm | 76 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | yes | 100 psi | angle | yes | yes | 3 db(a) | iso 11148-6 | 2006/42/ec | 8 mm | in-line | ||||||||||
lto38 r32-10-li4 | 8431061338 | 15 ft lb | 30 ft lb | 220 r/min | 7.1 lb | 494 mm | 82 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | yes | 100 psi | crowfoot | yes | yes | 93 db(a) | 3 db(a) | iso 11148-6 | 2006/42/ec | in-line | |||||||||||||||||||
ltc28 r18-10-li3 | 8431061602 | 7 ft lb | 13 ft lb | 386 r/min | 4 lb | 421 mm | 10 mm | 34 mm | 15 mm | 12.5 mm | 36.7 mm | 59.2 mm | 35 mm | 22 mm | 10 mm | 76 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | in-line | yes | 100 psi | angle | yes | yes | 3 db(a) | iso 11148-6 | 2006/42/ec | |||||||||||
lto28 r19-10-li3 | 8431061707 | 6 ft lb | 14 ft lb | 350 r/min | 4.2 lb | 402 mm | 10 mm | 34 mm | 14 mm | 13 mm | 31.9 mm | 29.7 mm | 35 mm | 38 mm | 11.2 mm | 82 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | yes | 100 psi | angle | yes | yes | 93 db(a) | 3 db(a) | iso 11148-6 | 2006/42/ec | 8 mm | in-line | |||||||||
ltc009 r14-10-li3 | 8431061356 | 3.6 ft lb | 10 ft lb | 175 r/min | 3.3 lb | 332 mm | 10 mm | 34 mm | 10 mm | 15 mm | 52 mm | 54.3 mm | 35 mm | 31 mm | 14.5 mm | 75 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | in-line | yes | angle | yes | yes | 3 db(a) | iso 11148-6 | 2006/42/ec | ||||||||||||
ltc39-2r60-13-lo5 | 8431062033 | 22 ft lb | 44 ft lb | 305 r/min | 7.3 lb | 590 mm | 13 mm | 81 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | crowfoot | yes | yes | 92 db(a) | 3 db(a) | 16 l/s | 1/4 inch | m10 mm | iso 11148-6 | 2006/42/ec | 10 mm | 3 m/s² | |||||||||||||
ltc39-2r23-14-lo5 | 8431061971 | 7 ft lb | 17 ft lb | 530 r/min | 5.5 lb | 515 mm | 14 mm | 81 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | angle | yes | yes | 92 db(a) | 3 db(a) | 16 l/s | 1/4 inch | m6 mm | iso 11148-6 | 2006/42/ec | 10 mm | 3 m/s² | |||||||||||||
ltc39-2r28-12-lo5 | 8431061508 | 13 ft lb | 21 ft lb | 560 r/min | 5.6 lb | 488 mm | 12 mm | 69.5 mm | 15 mm | 62 mm | 84 mm | 97 mm | 44 mm | 30 mm | 13 mm | 81 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | crowfoot | yes | yes | 92 db(a) | 3 db(a) | 16 l/s | 1/4 inch | m8 mm | iso 11148-6 | 2006/42/ec | 119 mm | 10 mm | 3 m/s² | ||||
lto38 r40-17-lo3 | 8431061911 | 16 ft lb | 30 ft lb | 200 r/min | 6.6 lb | 473 mm | 17 mm | 82 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | yes | 100 psig | crowfoot | yes | yes | 93 db(a) | 3 db(a) | iso 11148-6 | 2006/42/ec | offset | ||||||||||||||||||
ltc48 r105-24-li3 | 8431062054 | 37 ft lb | 77 ft lb | 162 r/min | 11.2 lb | 651 mm | 84 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | in-line | yes | 100 psi | crowfoot | yes | yes | 95 db(a) | 3 db(a) | iso 11148-6 | 2006/42/ec | |||||||||||||||||||
ltc39-2r16-14sfe12-lo5 | 8433232390 | 6.6 ft lb | 11.8 ft lb | 870 r/min | 5.5 lb | 477 mm | 14 mm | 81 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | crowfoot | yes | yes | 92 db(a) | 3 db(a) | 16 l/s | 1/4 inch | m6 mm | iso 11148-6 | 2006/42/ec | 10 mm | 3 m/s² | |||||||||||||
ltc39-2r50-15e8-lo4 | 8431062085 | 22 ft lb | 37 ft lb | 300 r/min | 7.3 lb | 575 mm | 15 mm | 81 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | crowfoot | yes | yes | 92 db(a) | 3 db(a) | 16 l/s | 1/4 inch | m10 mm | iso 11148-6 | 2006/42/ec | 10 mm | 3 m/s² | |||||||||||||
lto28 r17-13-li3 | 8431061248 | 6 ft lb | 13 ft lb | 350 r/min | 4.2 lb | 415 mm | 13 mm | 34 mm | 11 mm | 14.5 mm | 36.3 mm | 32.3 mm | 35 mm | 38 mm | 12.4 mm | 76 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | yes | 100 psi | angle | yes | yes | 3 db(a) | iso 11148-6 | 2006/42/ec | 8.5 mm | in-line | ||||||||||
ltc48 r135-22-li3 | 8431061615 | 77 ft lb | 100 ft lb | 90 r/min | 10.2 lb | 651 mm | 22 mm | 46 mm | 33 mm | 14 mm | 77.5 mm | 84 mm | 64 mm | 40 mm | 20 mm | 84 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | in-line | 100 psi | angle | yes | yes | 95 db(a) | 3 db(a) | iso 11148-6 | 2006/42/ec | |||||||||||
lto28 r12-12-lo5 | 8431061805 | 4.4 ft lb | 9 ft lb | 470 r/min | 4.4 lb | 402 mm | 12 mm | 66.5 mm | 11 mm | 51 mm | 73 mm | 84.9 mm | 44 mm | 11.9 mm | 76 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | yes | 100 psi | angle | yes | yes | 3 db(a) | iso 11148-6 | 2006/42/ec | 106.9 mm | 8 mm | offset | ||||||||||
ltc39-2 r28-13e15-lo5 | 8431061537 | 12 ft lb | 12 ft lb | 560 r/min | 5 lb | 500 mm | 13 mm | 81 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | crowfoot | yes | yes | 92 db(a) | 3 db(a) | 16 l/s | 1/4 inch | m8 mm | iso 11148-6 | 2006/42/ec | 10 mm | 3 m/s² | |||||||||||||
ltc39-2r40-14-lo3 | 8431061511 | 16 ft lb | 29 ft lb | 460 r/min | 5.3 lb | 452 mm | 14 mm | 77.8 mm | 18 mm | 24.8 mm | 46.8 mm | 61.3 mm | 44 mm | 31 mm | 14.5 mm | 81 db(a) | iso15744 | iso28927-2 | <2.5 m/s² | offset | yes | 100 psig | crowfoot | yes | yes | 92 db(a) | 3 db(a) | 16 l/s | 1/4 inch | m8 mm | iso 11148-6 | 2006/42/ec | 83.3 mm | 10 mm | 3 m/s² |
阿特拉斯ltc29-2r19-10-lo3角度扳手
